Description
This Trek Rail+ 5 Gen 5 Lithium Grey is available with our legendary Podium Point free accessory scheme.
Please note: This model features tubeless ready wheels and tyres which offer a superior ride and less rolling resistance than traditional innertubes. This system requires tyre sealant to function correctly and this will be fitted in our workshop prior to despatch. The nature of this sealant means that the tyre may not be fully sealed until it has been ridden a short distance and therefore the bicycle may arrive with reduced pressure in the tyres. Please check the bicycle's tyres are inflated to the recommended pressure before cycling.
Please note: This model offers electric assistance up to speeds of 25kph (15.6mph).
IMPORTANT: This bicycle requires a suspension pump to set and tune its suspension correctly. This is not included as standard. A suspension pump can be selected for no cost using Podium Points™.
Specification
Year
Generation 5
Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, Boost148, 12 mm thru axle, 160 mm travel
Fork
RockShox Psylo Gold RC, DebonAir spring, Isolator RC damper, tapered steerer, 44 mm offset, Boost 110, 15 mm Maxle Stealth, 160 mm travel
Rear Shock
RockShox Deluxe Select+ RT, 205 mm x 65mm
Motor
Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Control System
Bosch System Controller BRC3100, smart system
Battery
Bosch PowerTube 800 Wh, smart system
Display
Shifters
Shimano Deore M6100, 12-speed
Rear Mech
Shimano Deore M6100, long cage
Front Mech
Bottom Bracket
Chainset
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Brakes
Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
Pedals
VP-536 nylon platform
Wheelset
F: Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle - Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Bontrager Switch thru-axle, removable lever -
R:
Tyres
Size: S, M, L, XL - Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40"
Size: M, L, XL - Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Grips
Bontrager XR Trail Comp, nylon lock-on
Seatpost
Size: S - TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm
Size: M, L, XL - TranzX JD-YSI34, 170mm travel, internal routing, 34.9 mm
Saddle
Bontrager Verse P3, steel rails
Headset
Extras
Charger - Bosch standard 2A, 230V, smart system
Warranty
We are an authorised Trek dealer and supply this Trek Rail+ 5 Gen 5 Lithium Grey with a LIFETIME manufacturer's warranty. Read Warranty Terms
Sizing
Size
S
5'1"-5'5"
1.55-1.65
0.74-0.78
M
5'5"-5'9"
1.65-1.76
0.79-0.83
L
5'10"-6'2"
1.77-1.88
0.84-0.89
XL
6'2"-6'5"
1.88-1.95
0.89-0.91
Sizing information is provided as a general guide only. This is based on the average rider riding the bicycle in the style for which it is intended. This takes no account of a rider's personal proportions, physique, flexibility and biomechanics. If your height places you on, or near, a bicycle size step then we recommend you consider both sizes. All bicycles offer a range of handlebar and saddle adjustment which will enable you to fine tune your riding position once the correct size has been established. If you are unsure on sizing, we strongly recommend you visit our store so we can assist you. Pedal On offers advice and information on sizing in good faith, the final decision and responsibility on which size to purchase is yours.
Geometry
