Description
This Trek Marlin+ 6 Black is available with our legendary Podium Point free accessory scheme.
The Marlin+ is an affordable e-mountain bike that combines the best features of Trek and Bosch to enhance off-road rides. With the reliable Bosch Active Line Plus mid-drive motor and Trek's renowned bike design, this e-MTB offers seamless pedal-assist for enjoyable extended rides on trails and in urban environments. The Marlin+ doesn’t skimp on performance and reliability, instead blending them together to deliver a premium e-MTB experience at a price that’s accessible to a wide range of riders.
The new Bosch Active Line Plus mid-drive motor delivers the same refined performance and reliability you’ve come to expect from Bosch. It puts out a mid-power 50 Nm of torque which draws less power from the battery and doesn’t overwhelm the rider. It’s also much quieter than high-powered e-bikes.
Bosch CompactTube 400 - A 400-watt-hour battery is fixed inside the downtube. The new battery is more energy dense, which means more power in a lighter, smaller package.
Bosch Purion 200 - The display and remote are now combined into one simple, beautiful piece. The full colour display provides all the information riders need in a compact package.
AUTO mode - In the spirit of keeping things simple and fun, an 'AUTO' mode provides adaptive motor support so riders can hit the trail without worrying about which mode they’re in. If you run into a hilly section or headwind, the motor will increase support accordingly so you can pay attention to the ride instead of fiddling with your bike.
Marlin+ is equipped with fast rolling 29’’ wheels with grippy 2.6’’ tyres for tons of traction and all-sort of off-road versatility. Extra-small and Small frame sizes are equipped with more proportional 27.5’’ wheels.
A 120 mm* travel front suspension fork flattens out roots, rocks and bumps in the trail. A dropper seat post makes it easy to get the saddle out of the way. Front and rear thru-axles add stiffness for precise handling, while a Universal Derailleur Hanger (UDH) makes service easy and future upgrades possible. (*100mm on XS)
The Marlin+ is the go-to for riders looking to dip their toes into the electric mountain bike world. Its trail-savvy frame gives you confident control, and a Bosch Active Line Plus motor offers enough power to take the burn out of long climbs.
Please note: This model offers electric assistance up to speeds of 25kph (15.6mph).
Specification
Year
2025
Frame
Alpha Platinum Aluminium, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle. Curved Top tube on XS
Fork
SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 120 mm travel. 100mm travel on XS.
Rear Shock
N/A
Motor
Bosch Active Line Plus, 50 Nm
Control System
Bosch Active Line Plus
Battery
Bosch CompactTube 400 Wh
Display
Bosch Purion 200
Shifters
Shimano U4000, 9-speed
Rear Mech
Shimano CUES U4000
Front Mech
N/A
Bottom Bracket
Bosch
Chainset
FSA CK-220, 165 mm length
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500, 9/10/11-speed
Brakes
Tektro HD-M275 hydraulic disc
Pedals
VP-536 nylon platform
Wheelset
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve. Hubs: Bontrager alloy, sealed bearing, alloy axle
Tyres
Size: XS , S - Bontrager XT3 Comp, wire bead, 30 tpi, 27.5x2.40". Size: M , L , XL - Bontrager XT3 Comp, wire bead, 30 tpi, 29x2.40"
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise
Stem
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree
Grips
Bontrager XR Endurance Comp, lock-on
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset
Saddle
Bontrager Arvada, steel rails, 138 mm width
Headset
Semi-integrated, loose ball bearing, 1-1/8" top, 1.5" bottom
Extras
Bosch standard 2A, 230V, smart system
Warranty
We are an authorised Trek dealer and supply this Trek Marlin+ 6 Black with a LIFETIME manufacturer's warranty. Read Warranty Terms
