*In Stock - Not all In Stock bikes are on display. If you would like to collect or view a bike in store, please use our Click & Collect payment method or call 0118 9821021 to reserve and ensure your bike is ready for your visit.
ETAs are based on manufacturer's latest data.
Please note that we are unable to ship this Liv Intrigue X Advanced E+ Elite 1 outside of the UK.
Important lead time information
Where delivery times are stated as an ETA month this is based on the latest information from the manufacturer. These dates should be treated as a guide and may be subject to change. Due to an increased strain in global supply chains, factory and shipping schedules can be easily disrupted.
Should you place a future order with us we will monitor the bike’s ETA and keep you informed of any changes.
For more detailed information please read here.
Description
Please note: This model features tubeless ready wheels and tyres which offer a superior ride and less rolling resistance than traditional innertubes. This system requires tyre sealant to function correctly and this will be fitted in our workshop prior to despatch. The nature of this sealant means that the tyre may not be fully sealed until it has been ridden a short distance and therefore the bicycle may arrive with reduced pressure in the tyres. Please check the bicycle's tyres are inflated to the recommended pressure before cycling.
Please note: This model offers electric assistance up to speeds of 25kph (15.6mph).
IMPORTANT: This bicycle is supplied without pedals.
IMPORTANT: This bicycle requires a suspension pump to set and tune its suspension correctly. This is not included as standard.
Specification
Year
2023
Frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system MX (front 29", rear 27.5")
Fork
Fox 36 Performance Elite Live Valve, 150mm travel, 44mm offset, Grip2 damper, Boost 110x15QR, electronic adaptive suspension, e-bike integrated, e-bike integrated
Rear Shock
Fox Float X Live Valve, 185x52.5mm Trunnion mount, electronic suspension, e-bike integrated
Motor
SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
Control System
RideControl Ergo3, grip integrated remote
Battery
EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, EnergyPak Plus 200 range extender compatible
Display
RideControl GO, frame integrated LED console Optional wireless ANT+ display
Shifters
SRAM AXS Rocker Paddle, wireless electronic shifting
Rear Mech
SRAM GX Eagle AXS
Front Mech
MRP 1X HD2 custom co-molded chain guide
Bottom Bracket
n/a
Chainset
Praxis Performance Carbon e-crank arms (XS/S:160, M:165) SRAM X-SYNC Eagle 36T chain ring
Cassette
SRAM XG-1275, 10-52T, 12-speed
Chain
SRAM GX Eagle PowerLock
Brakes
SRAM Code R, hydraulic disc, 220mm[F] /200mm[R]
Pedals
Not Supplied
Wheelset
TRX 2 Hookless Clincher, 29" [F] / 27.5" [R], 30mm inner width
Tyres
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F] Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
Handlebar
Giant Contact SLR Trail, carbon, 760mm (XS-S), 800mm (M)
Stem
Giant Contact SLR Trail, integrated, 40/45/50mm Reach, 7/9degree Sweep Adjust System
Grips
Liv Tactal Pro-E Single Lock-On Grips
Seatpost
Tranz-X Rad+ dropper, 30,9mm, 30mm travel adjustable (XS/S:90-125mm, M:120-150mm)
Saddle
Liv Sylvia E+
Headset
Extras
EnergyPak 4A smart charger, 60% in 1:45, Tubeless Setup
Warranty
We are an authorised Liv dealer and supply this Liv Intrigue X Advanced E+ Elite 1 with a LIFETIME manufacturer's warranty. Read Warranty Terms
Sizing
Size
XS
5'0"-5'4"
1.52-1.63
S
5'2"-5'7"
1.58-1.69
M
5'5"-5'9"
1.64-1.75
Sizing information is provided as a general guide only. This is based on the average rider riding the bicycle in the style for which it is intended. This takes no account of a rider's personal proportions, physique, flexibility and biomechanics. If your height places you on, or near, a bicycle size step then we recommend you consider both sizes. All bicycles offer a range of handlebar and saddle adjustment which will enable you to fine tune your riding position once the correct size has been established. If you are unsure on sizing, we strongly recommend you visit our store so we can assist you. Pedal On offers advice and information on sizing in good faith, the final decision and responsibility on which size to purchase is yours.
