Description
A new breed of trail bike that blends power, performance and flat-out fun. with its lightweight composite frame, plush suspension and new motor technology, you'll never want the ride to end.
Powerful and responsive - SyncDrive Pro motor with 85Nm of torque creates powerful pedalling assistance even at low speeds. Lightweight, stiff Advanced-grade composite frame with 140mm of Maestro rear suspension travel and 150mm up front delivers confident handling and control on rough trails.
Adaptable to the terrain - Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style. You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.
Clean cockpit - RideControl Go top tube integrated multi-function on/off button and RideControl Ergo 3 handlebar-mounted remote, which can be mounted on either grip, offer user-friendly controls and an uncluttered cockpit design.
Please note: This model features tubeless ready wheels and tyres which offer a superior ride and less rolling resistance than traditional innertubes. This system requires tyre sealant to function correctly and this will be fitted in our workshop prior to despatch. The nature of this sealant means that the tyre may not be fully sealed until it has been ridden a short distance and therefore the bicycle may arrive with reduced pressure in the tyres. Please check the bicycle's tyres are inflated to the recommended pressure before cycling.
Please note: This model offers electric assistance up to speeds of 25kph (15.6mph).
IMPORTANT: This bicycle is supplied without pedals.
IMPORTANT: This bicycle requires a suspension pump to set and tune its suspension correctly. This is not included as standard.
Specification
Year
2023
Frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible
Fork
Fox 36 Float Performance E-Tuned, 29er, 150mm travel, 44mm offset, Grip 3-position Micro Adjust damper, Kabolt-X 110
Rear Shock
Fox DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
Motor
Giant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
Control System
Giant RideControl Ergo3, grip integrated remote
Battery
Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible
Display
Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
Shifters
Shimano Deore SLX
Rear Mech
Shimano Deore SLX, 12-speed, Shadow+
Front Mech
MRP HD2 co-moulded chain guide
Bottom Bracket
n/a
Chainset
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S:160mm, M/L: 165mm, XL:170mm)
Cassette
Shimano CS-M6100, 10-51T, 12-speed
Chain
KMC e.12 Sport, NP/NP, e-bike optimised
Brakes
Shimano SLX, BR-M7120, 4-piston, hydraulic disc, 203mm
Pedals
Flatpedal
Wheelset
Rims: Giant AM 29", Tubeless ready, 30mm inner width, e-bike optimised, Hubs: Shimano MT410, Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Tyres
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F] Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R]
Handlebar
Giant Contact 35 Trail, 35x780mm
Stem
Giant Contact SL 35
Grips
Giant Tactal Pro-E, single lock-on
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
Saddle
Giant Romero, Neutral
Headset
Extras
Giant EnergyPak 6A smart charger, 60% in 3:00h, Tubeless Setup
Warranty
We are an authorised Giant dealer and supply this Giant Trance X Advanced E+ 2 with a LIFETIME manufacturer's warranty. Read Warranty Terms
Sizing
Size
S
5'4"-5'8"
1.63-1.72
M
5'7"-5'11"
1.71-1.80
L
5'10"-6'2"
1.79-1.88
XL
6'2"-Above
1.87-Above
Sizing information is provided as a general guide only. This is based on the average rider riding the bicycle in the style for which it is intended. This takes no account of a rider's personal proportions, physique, flexibility and biomechanics. If your height places you on, or near, a bicycle size step then we recommend you consider both sizes. All bicycles offer a range of handlebar and saddle adjustment which will enable you to fine tune your riding position once the correct size has been established. If you are unsure on sizing, we strongly recommend you visit our store so we can assist you. Pedal On offers advice and information on sizing in good faith, the final decision and responsibility on which size to purchase is yours.
